Here you will find current measurements of various types of aftermarket LED's for cars, approx 13v power supply has been used on all. (Updated 28/10/2018)

To establish a baseline measurement first we have a normal Incandescent C5W, note the voltage drop to 10.8v due to the resistance of the bulb

To calculate the wattage of each light use the formula P=I×V (watt = amp × volt) so the Incandescent C5W is 6.8 watts

We can also calculate the resistance by using the formula R=V/I so the Incandescent C5W has a calculated resistance of 17.1 Ω

If you wish to comment or make suggestions please click here Comments





1 - 8000k "CANBUS" COB (Chip On Board) C5W

2 - 8 SMD "CANBUS" Festoon C5W

3 - 6500k COB C5W

4 - 16 SMD 4014 Festoon C5W

5 - Glass Tube COB C5W

6 - 1x Cree R2 "CANBUS" C5W

7 - 2xCREE Q5 XP-E plus 4x5730SMD C5W

8 - Gold "CANBUS" 9SMD

9 - Black "CANBUS" 6SMD

10 -Gold "CANBUS" Festoon with x2 Samsung 3623 Chips C5W

11 - 6 SMD "CANBUS" T10

12 - White 10 SMD "CANBUS" T10

13 - Blue 10 SMD "CANBUS" T10

14 - Ice Blue 10 SMD "CANBUS" T10

15 - Red 10 SMD "CANBUS" T10

16 - COB "CANBUS" T10

17 - 3x Cree R2 "CANBUS" T10

18 - T15 "CANBUS" 15SMD

19 - Gold "CANBUS" T10 9 SMD

20 - Silicone encased COB T10 White Long

21 - Silicone encased COB T10 Blue Long

22 - Silicone encased COB T10 White Short

23 - Silicone encased COB T10 Blue Short

24 - 5SMD T10

25 - BA9S COB 6 LED Chips

26 - BA9S LED

27 - 28mm 24 SMD Festoon

28 - Glass Tube 12SMD double sided Festoon

30 - Glass Tube 6SMD double sided Festoon

31 - Red 6 SMD Festoon

31 - Blue 6 SMD Festoon

32 - Red 8 SMD Festoon

33 - Blue 8 SMD Festoon

34 - Green 6 SMD Festoon

35 - T10 1 SMD

36 - Silicone encased 6 SMD T10 (Epistar chips)

37 - Silicone encased 24 SMD (3014 chips) T10

38 - T10 Silicone Filament COB White/Red/Blue
